Application:
Suitable for the pharmaceutical, food and cosmetics industries.Construction offers a good balance between strength and light weight, making this ABCOFLEX hose easy to handle and also suitable and shorter lengths. It can be used both as a pressure and suction hose or as a vibration damper.
Construction:
Smooth Silicone inner and outer lining. Polyester reinforcement, close-lapped stainless steel spiral. The hose meets USP class VI, FDA CFR 177.2600, BFR part XV Standards.
Temperature Range:
-60°C - +200°C
| Code |
ID |
OD |
Working Pressure |
BURST Pressure |
Minimum Bend Radius |
Vacuum |
|
MM |
MM |
BAR |
BAR |
MM |
MM of Hg |
| PSV10 |
08 |
16 |
10.5 |
42 |
35 |
760 |
| PSV10 |
08 |
16 |
10.5 |
42 |
35 |
760 |
| PSV12 |
13 |
23 |
10.5 |
42 |
50 |
760 |
| PSV16 |
16 |
25 |
10.5 |
42 |
65 |
760 |
| PSV20 |
20 |
29 |
10.5 |
42 |
65 |
760 |
| PSV25 |
25 |
36 |
10.5 |
42 |
90 |
760 |
| PSV38 |
38 |
48 |
10.5 |
42 |
100 |
760 |
| PSV50 |
50 |
61 |
8.5 |
35 |
150 |
760 |
| PSV65 |
63 |
74 |
8.5 |
35 |
280 |
760 |
| PSV76 |
76 |
86 |
4 |
28 |
350 |
700 |
| PSV100 |
101 |
117 |
3 |
12 |
400 |
600 |
Available In:
